Superbooth 23

Superbooth 2023 is coming up and I am finally going there again. The last time I was there must have been in 2019 and I really missed it. I won’t have a booth there but I will be around on Friday the 12th of June if you want to meet up and have a chat. I think the easiest is…

Read More

VCO

VCO is a basic analog sawtooth core voltage controlled oscillator based on the electronotes circuit ENS-76 option 1. It’s frequency range is 32Hz to 6.5kHz and additionally to it’s sawtooth output it provides triangle and square out. Beseides a Caorse and a fine tuen knob there is also a linear FM input with attenuation. Width: 6 HPPower Consumption: 19mA @ +12V |…

Read More

The Eurorack Standard: All you need to know!

Introduction The Eurorack standard is a modular synthesizer format that has become increasingly popular in the world of electronic music production. It was first developed by Dieter Doepfer in Germany in the late 1990s and has since grown to become one of the most widely used formats for modular synthesizers. In this article, we will take a closer look at…

Read More

Planning a Eurorack Modular Synth: A beginners guide

This Guide shows an easy and failsafe strategy how to plan your first Eurorack Modular Synth. If you’re just getting started with modular synthesizers, planning a new Modular System is a challenging task. The vast amount of modules available is just overwhelming and can make a decision for the right module pretty difficult. Below I want to show you a…

Read More

TETRA VCA

Tetra VCA Solisynth

TetraVCA is a Quad Voltage Controlled Amplifier with an adjustable response curve from linear to exponential. The Control Voltage inputs all have an indvidual level control, a LED indicator and you can choose between attenuation or attenuvertion of the CV signal by flipping a switch. This allows you to amplitude modulate your signal in a more flexible way! Each channels…

Read More

STERO MIXER

The ‘Stereo Mixer’ is a 3 Channel Stereo Mixer with additional mono sum output and clipping indication LEDs.The left signal is forwarded to the right channel If nothing is plugged in the right channels input. This enables easy mixing of stereo and mono input signals.Both inputs are DC coupled, therefore the module can be used for mixing control voltages as…

Read More

How to Order Printed Circuit Boards

This is a guide on how to order PCBs and what to keep in mind when doing so. I am giving a short overview what Data the Manufacturer requires to build your Printed Circuit Boards and what manufacturing options you should choose for getting the best results. Required Data For ordering PCBs from a manufacturing house you have to provide…

Read More
